Wall-Mounted Fan Coils HWF

These are wall-mounted fan coil units designed for heating and cooling rooms using water-based systems (heat pumps or boilers). They are installed high on the wall, do not take up floor space, and ensure fast and even temperature distribution throughout the room.
They are suitable for residential and commercial spaces where a compact, quiet, and efficient climate control solution is required.

Description
Tech. specifications
Dimensions
Download
Accessories
Order Codes

Energy Efficiency: DC motors offer higher energy efficiency, especially at lower speeds, consuming up to 70% less electricity than AC motors.
Quiet Operation: DC motors operate extremely quietly, making them ideal for spaces where low noise levels are important.
Longer Lifespan: Due to lower heat generation during operation, DC motor fans have a longer lifespan.
Wide Speed Control Range: DC motors allow precise airflow regulation, ensuring optimal comfort.
Heat exchangers with hydrophilic fins
Improved heat transfer: The hydrophilic coating improves condensate drainage from the heat exchanger surface, thereby increasing heat exchange efficiency.
Corrosion Protection: The hydrophilic coating protects the fins from corrosion, extending the unit’s lifespan.
Energy Saving: Efficient heat transfer reduces energy consumption as the unit requires less effort to maintain the set temperature.
Less frequent maintenance required: The coating reduces the accumulation of dust and dirt, making the unit easier to maintain.
All models are equipped with nylon inlet air filters.
A remote control is included as standard. Main functions:
Operating Modes: automatic, heating, cooling, dehumidification, ventilation
Temperature Control: precise room climate management
Adjustment of the air swing range
Airflow direction control: the air is directed where it is needed most
Sleep Mode: optimized conditions for quality rest
Timer: ability to set the unit’s operating time
Space-Saving Design: Mounted high on the wall, the units do not occupy floor space, making them ideal for spaces where efficient use of space is important.
Efficient Air Distribution: Mounted higher, ensuring even air distribution throughout the room and uniform temperature from floor to ceiling.
Quiet Operation: The units are designed to operate extremely quietly, ensuring a comfortable environment in both residential and commercial spaces.
Aesthetic Design: Modern and elegant shapes allow the units to blend harmoniously into any interior and enhance its aesthetics.
Individual Control: Each unit is controlled separately, allowing for individual comfort settings in different rooms.

Actuator for Thermostatic Valve A24NC

For opening/closing the thermostatic valve. Controlled by room thermostat TW24

Operating voltage - 24V DC

E power - 2.5W

Protection class IP

Connection thread - M30 x 1.5mm

E power - 1.5W

Thermostatic Valve (Straight) TVS15

For regulating the energy carrier flow. Controlled by actuator A24NC

Operating temperature -10℃ - 120℃

Thread 1/2″

Pressure class - PN10

Kvs - 2.00

Body - nickel-plated bronze

Return Flow Limiter (Straight) LS15

For opening, closing, and setting the maximum flow of the energy carrier

Operating temperature -10℃ - 120℃

Thread 1/2″

Pressure class - PN10

Kvs - 2.00

Body - nickel-plated bronze

Return Flow Limiter (Angled) LA15

For opening, closing, and setting the maximum flow of the energy carrier

Operating temperature -10℃ - 120℃

Thread 1/2″

Pressure class - PN10

Kvs - 2.00

Body - nickel-plated bronze

CONVECTOR ORDER CODE

MODELLENGTH, cm WIDTH, cmHEIGHT, cmEXAMPLE
HWF-518529,120,3HWF 51
HWF-102108,132,724,8HWF 102

ACCESSORY ORDER CODES

ORDER
MODELCODE
Straight return flow limiterLS15
Angled return flow limiterLA15
Straight thermostatic valveTVS15
Elektroterminė pavara 24VA24NC
