Floor convectors without fans FC
Heating by natural convection – without fans
Low thermal inertia allows delivering heat only as needed, thus significantly reducing energy consumption and avoiding overheating of rooms
Silent – suitable for rooms with strict acoustic requirements
Reliable and durable solution, requiring minimal maintenance
Wide range of sizes and heating capacities from 160 models
Robust stainless steel casings, designed for pedestrian loads and capable of supporting the weight of several adults
Double-sided aesthetic grilles made of aluminum or oak wood
10-year warranty on the entire device
Designed and manufactured in Lithuania
Silent
casings
water volume
FC series natural convection floor convectors are designed for room heating without fans, using the principle of natural air circulation.
The units operate completely silently, making them particularly suitable for rooms with high acoustic comfort requirements, such as bedrooms, hotel rooms, or living spaces.
Due to their reliable construction without moving parts, FC convectors have an exceptionally long service life and require no complex maintenance.
Low thermal inertia allows for quick response to temperature changes, making FC one of the most economical solutions, enabling precise maintenance of the set room temperature (up to ±0.5 °C).
Convectors are equipped with robust stainless steel casings, ensuring durability and reliable operation even in high-traffic areas.
The FC design is adapted for pedestrian loads – it can be safely walked on and supports the weight of several adults.
For architectural integration, double-sided aesthetic grilles made of aluminum or oak wood are used, allowing the solution to be adapted to the flooring and interior concept.
- Stainless steel casing – 1 pc.
- Casing reinforcement elements – 2-7 pcs.
- Cover for hydraulic connections – 1 pc.
- Air deflection element – 1-2 pcs.
- Anodized aluminum frame; color matches grille color – 1 set
- Copper-aluminum heat exchanger – 1 pc.
- Vent – 1 pc.
- Protective – decorative grilles (ordered separately) – 1 pc.
- Adjustable height legs – 4-20 pcs.
- Sound-insulating leg pads – 4-20 pcs.
- Elements for attaching the casing to the floor – 4 pcs.
- Sound-insulating gaskets – 4 pcs.
- Heat exchanger mounting – protection elements – 4-14 pcs.
- Pipe sealing – protection elements – 2 pcs.
- Cable sealing – protection elements – 1 pc.
- Blanks for unused openings – 4 pcs.
Mounting details
Installation instructions
5-layer, 2-part corrugated cardboard box, also used as a protective cover for the device during construction work
ROLL-UP ALUMINUM GRILLES GR
SILVER (ALS)
BROWN (AL10)
BLACK (AL50)
LINEAR ALUMINUM GRILLES GR-L
SILVER (ALS)
BROWN (AL10)
BLACK (AL50)
ROLL-UP WOODEN GRILLES GR
OAK (OAK)
Room Thermostat TW24
For maintaining the set room temperature. Controls actuator A24NC
Dimensions 88 x 88 mm
Weekly temperature schedule programming
Operating temperature 5 - 35°C
Operating voltage - 24V DC, current - 3A
E power - 1.5W
Thermostatic Valve (Straight) TVSP15
For regulating the energy carrier flow. Controlled by actuator A24NC
Operating temperature -10℃ - 120℃
Thread 1/2″
Pressure class - PN10
Kvs - 2.00
Body - nickel-plated bronze
Return Flow Limiter (Straight) LS15
For opening, closing, and setting the maximum flow of the energy carrier
Operating temperature -10℃ - 120℃
Thread 1/2″
Pressure class - PN10
Kvs - 2.00
Body - nickel-plated bronze
Return Flow Limiter (Angled) LA15
For opening, closing, and setting the maximum flow of the energy carrier
Operating temperature -10℃ - 120℃
Thread 1/2″
Pressure class - PN10
Kvs - 2.00
Body - nickel-plated bronze
Actuator for Thermostatic Valve A24NC
For opening/closing the thermostatic valve. Controlled by room thermostat TW24
Operating voltage - 24V DC
E power - 2.5W
Protection class - IP54
Connection thread - M30 x 1.5mm
Casing material PC/ABS
Thermostatic Head THC
For maintaining the set room temperature. Controls thermostatic valve TVS15
Temperature range 0℃ - 27℃
Frost protection
Capillary tube length - 1.2 m
Connection thread - M30 x 1.5mm
Casing material - ABS
CONVECTOR ORDER CODE
| MODEL | LENGTH, cm | WIDTH, cm | HEIGHT, cm | EXAMPLE |
| FC | 100 | 32 | 11 | FC 100-32-11 |
GRILLE ORDER CODES
| MODEL | LENGTH, cm | WIDTH, cm | MATERIAL | EXAMPLE |
| GR | 200 | 32 | ALS | GR 200-32-ALS |
| GR-L | 140 | 22 | AL50 | GR-L 140-22-AL50 |
| GR – roll-up | ALS – aluminum, silver color | |
| GR-L – linear | AL10 – aluminum, brown | |
| AL50 – aluminum, black | ||
| OAK – oak | ||
ACCESSORY ORDER CODES
| MODEL | ORDER CODE |
| Return Flow Limiter Angled | LA15 |
| Return Flow Limiter Straight | LS15 |
| Thermostatic Valve Straight | TVSP15 |
| Thermostatic Valve Axial | TVA15 |
| Electrothermal Actuator 230V AC | A230NC |
| Room Thermostat | TW24 |
| Thermostatic Head with Capillary | THC |
